ESP8266 ESP32 ESP-32 Module ESP32-WROOM-32D 32U 32E 32UE ESP32-WROVER Series module for Internet of Things
ESP8266 ESP32 ESP-32 Module ESP32-WROOM-32D 32U 32E 32UE ESP32-WROVER Series module for Internet of Things
Regular price
$5.24 USD
Regular price
$2.62 USD
Sale price
$5.24 USD
Unit price
per
Shipping calculated at checkout.
SPECIFICATIONS
- Brand Name : SZYTF
- Model Number : ESP32-WROOM
- Sold in : sell_by_piece
- Origin : Mainland China
- each pack : 1
- Condition : New
- Measurement unit : 100000015
- Type : Voltage Regulator
- Package size - height (cm) : 10
- Package size - length (cm) : 10
- Package size - width (cm) : 10
- Package weight : 0.030
Introduction:
ESP32-WROOM-32U and ESP32-WROOM-32D are universal
Wi-Fi+BT+BLE MCU module, powerful and versatile, can be used for low power sensors
Network and demanding tasks such as voice coding, audio streaming and MP3 decoding.
Unlike the ESP32-WROOM-32D, the ESP32-WROOM-32U is integrated.
A U.FL cradle.
ESP32-WROVER-B is a universal Wi-Fi+BT+BLE MCU module with powerful functions
Large, versatile, can be used in low-power sensor networks and demanding tasks such as speech coding,
Audio stream and MP3 decoding, etc.
ESP32-WROVER-B has two modules, one with PCB onboard antenna and the other
Use an IPEX antenna. The ESP32-WROVER-B module is configured with 4 MB SPI flash and
8 MB SPI PSRAM.
SP32-WROVER is a universal Wi-Fi+BT+BLEMCU module with powerful functions.
Wide range of applications for low-power sensor networks and demanding tasks such as voice coding, audio
Stream and MP3 decoding, etc.
ESP32-WROVER has two modules, one with PCB onboard antenna and the other with
IPEX antenna. The ESP32-WROVER is configured with 4 MB SPI flash and 8 MB SPI PSRAM.
Features:
The module integrates traditional Bluetooth, low-power Bluetooth and Wi-Fi for a wide range of uses: Wi-Fi supports a wide range of communication connections and direct connection to the Internet via a router; Bluetooth allows users to connect to a mobile phone or broadcast BLE Beacon for signal detection. The ESP32 chip's sleep current is less than 5 μA, making it suitable for battery-powered wearable electronics. The module supports data rates up to 150 Mbps and antenna output power of 20 dBm for maximum wireless communication. As a result, this module has industry-leading specifications and performs well in terms of high integration, wireless transmission distance, power consumption, and network connectivity.
ESP-WROOM-32
Introduction:
1. ESP32 is a single-chip solution that integrates 2.4 GHz Wi-Fi and Bluetooth dual-mode, using TSMC's ultra-low-power 40-nm process.Optimal power performance, RF performance, stability, versatility and reliability for a wide range of applications and different power requirements.
2. ESP32 is designed for mobile devices, wearable electronics and Internet of Things (IoT) applications. As the industry's leading low power chip, ESP32 has Fine-resolution features such as clock gating, power-saving modes, and dynamic voltage scaling.For example, in a low-power IoT sensor Hub application scenario, ESP32 will only be periodically woken up under certain conditions. Low duty cycle can make
3. The energy consumption of the ESP32 chip reaches a small value. The output power of the RF power amplifier can also be adjusted to achieve the most balanced communication distance, data rate and power consumption.
4. ESP32 is designed for mobile devices, wearable electronics and Internet of Things (IoT) applications. As the industry's leading low power chip, ESP32 has Fine-resolution features such as clock gating, power-saving modes, and dynamic voltage scaling.
5. The energy consumption of the ESP32 chip reaches a small value. The output power of the RF power amplifier can also be adjusted to achieve a balance between communication distance, data rate and power consumption.
WiFi:
• 802.11 b/g/n/e/i
• 802.11 n (2.4 GHz) with speeds up to 150 Mbps
• 802.11 e: QoS mechanism for wireless multimedia technology
• WMM-PS, UAPSD
• A-MPDU and A-MSDU frame aggregation technology
• Block reply
• Fragmentation and reorganization
• Beacon automatic monitoring / scanning
• 802.11 i security features: pre-authentication and TSN
• Support WPA / WPA2 / WPA2-Enterprise / WPS encryption
• Infrastructure BSS Station Mode / SoftAP Mode
• Wi-Fi Direct (P2P), P2P discovery, P2P GO mode and P2P power management
• UMA compatibility and certification
• Antenna diversity and selection
Bluetooth:
• Bluetooth v4.2 full standard, including traditional Bluetooth (BR/EDR) and Bluetooth Low Energy (BLE)
• Supports standard Class-1, Class-2 and Class-3 without external power amplifier
• Enhanced precision power control
• Output power up to + 10 dBm
• NZIF receiver with BLE reception sensitivity of -98 dBm
• Adaptive Frequency Hopping (AFH)
• Standard HCI based on SDIO / SPI / UART interface
• High speed UART HCI up to 4 Mbps
• Support for BT 4.2 controller and host protocol stack
• Service Discovery Protocol (SDP)
• Universal Access Application (GAP)
• Security Management Protocol (SMP)
• Bluetooth low energy
• ATT / GATT
• HID
• Supports all GATT-based Bluetooth low energy applications
• SPP-Like Bluetooth Low Energy Data Transfer Protocol
• BLE Beacon
• A2DP / AVRCP / SPP, HSP / HFP, RFCOMM
• CVSD and SBC audio codec algorithms
• Bluetooth piconet and Scatternet
|
|
|
|
|
|
|
|
|
|
|
|
